Low Inductance Power Resistor
The low inductance power resistor is a high-power aluminum housed resistor designed for high-frequency switching, transient energy absorption, and power electronics applications. With ultra-low parasitic inductance characteristics, it helps reduce voltage overshoot, switching ringing, and electromagnetic interference (EMI) in fast-switching circuits such as IGBT/SiC power systems, inverter equipment, DC link discharge circuits, and switching power supplies.
Featuring an optimized aluminum housing structure, this resistor provides efficient heat dissipation, high pulse load capability, and stable performance under demanding dynamic load conditions. Custom resistance values, power ratings, and mechanical configurations are available for industrial power conversion, energy storage, and advanced power electronics applications.
Key Features of Low Inductance Power Resistor
• Ultra-Low Inductance Design
Minimizes parasitic inductance, voltage overshoot, and switching ringing in high-frequency power electronics.
• High Power & Pulse Capability
Supports up to 2.2kW power rating with reliable energy absorption and overload performance.
• Compact Aluminum Housing
6061 aluminum structure provides efficient heat dissipation and high power density in limited space.
• Flexible Resistance & Customization
Custom resistance values, power ratings, terminals, and mounting configurations available.
• Stable High-Temperature Performance
Ni-Cr alloy element with low TCR ensures consistent resistance during thermal cycling.
• Modular Power Expansion
Multiple resistor modules can be combined for higher power requirements and system integration.
Why Ultra Low Inductance Matters
In high frequency switching systems, parasitic inductance can lead to voltage spikes, switching losses, and reduced system efficiency.This ultra low inductance power resistor minimizes these effects, ensuring cleaner signal performance and improved system stability, especially in fast-switching applications such as IGBT, SiC, and GaN-based designs.
Applications of Low Inductance Power Resistor
Applications of Low Inductance Power Resistor
– High frequency switching power supplies
– IGBT, SiC and power semiconductor testing
– Inverter and converter systems
– DC link discharge and energy absorption circuits
– Industrial automation and motor drives
– Battery energy storage systems (BESS)
– DC-DC converters and UPS systems
| Application | Why Low Inductance Resistor Is Used |
|---|---|
| IGBT / SiC Switching Circuits | Reduces voltage spikes and switching ringing during fast switching |
| DC Link Discharge | Provides reliable energy absorption during capacitor discharge |
| Inverter Systems | Handles transient energy and improves system stability |
| Pulse Load Testing | Supports short-duration high-energy pulses |
| Power Semiconductor Testing | Provides stable load conditions for device evaluation |
Customization Options
We provide flexible customization based on your project requirements:
– Resistance value
– Power rating
– Terminal structure
– Mounting type
– Lead configuration
Our engineering team can assist in optimizing the resistor for your specific application environment.
