The 100W VFD Braking Resistor with Aluminum Housing is engineered to safely dissipate excess energy generated during deceleration in variable frequency drive (VFD) systems. Its sturdy aluminum enclosure provides excellent heat dissipation, ensuring stable operation under continuous load. Designed for industrial AC motor control, power inverters, and high-reliability drive systems, this VFD braking resistor delivers consistent braking performance, long-term durability, and reliable thermal management.
Product Specifications
| Parameter | Value |
|---|---|
| Resistance Range | 1Ω – 1KΩ |
| Power Rating | 100W – 1000W |
| Tolerance | ±5% (or custom) |
| Operating Temp | -55°C to +300°C |
| Mounting | Screw/Bracket/Panel Mount |
| Housing Material | Anodized Aluminum |
| Protection Class | IP20 / IP50 optional |
| Compliance | RoHS, CE |
Dimension of VFD Braking Resistor
Applications
Helps dissipate excess energy during motor deceleration
Prevents overvoltage and protects inverter lifespan
Supports regenerative braking cycles
Ensures precise deceleration in high-speed servo systems
- Compatible with CNC machines, packaging lines
- The resistor dissipates energy effectively.
- As a result, it protects the inverter from overvoltage.
- Moreover, it performs well even under high temperature conditions.
Explore More Braking Resistor Options
For additional technical guidelines on braking resistors in automation systems, please refer to the
IEC official standards or
ABB’s industrial drives documentation.Looking for higher power or different mounting types?
- Check out our full range below 200W Aluminum Resistor Heat-Resistant Braking Solution
